CIRS 801-P男性骨盤模體，CIRS 801-P模體

CIRS 801-P男性骨盤模體是我們最現實的，組織當量幻像可用。模體被設計用于診斷放射學和放射zhi 療成像劑量學教學和示范應用。模體的所有解剖尺寸都基于可見人類項目（VHP）數據集，可作為人體解剖學研究的參考，可通過國家醫學圖書館獲取。

CIRS 801-P男性骨盤模體將這一解剖細節與我們先進的組織模擬技術相結合。CIRS 801-P男性骨盤模體由專有的環氧材料制成，模擬人類組織的密度和輻射衰減特性，從50keV到25MeV，范圍在1％以內。它包含解剖學上精確的骨，軟骨，脊髓，椎間盤，肌肉，腸，膀胱，前列腺，直腸和間質脂肪。



CIRS 801-P男性骨盤模體技術規格
尺寸： 35.6厘米×30.5厘米×25.4厘米（14“×12”×10“）
幻像重量： 24.9千克（55磅）
材料：環氧樹脂
密度： 0.96g / cc

CIRS 801-P男性骨盤模體包括的材料
男性骨盆模體
手提箱
用戶指南
保修信息
4年保修







CIRS 801-P男性骨盤模體，CIRS 801-P模體英文介紹：


The CIRS Model 801-P phantom is our most realistic, tissue equivalent phantom available.  The phantom was designed for use in diagnostic radiology and radiation therapy for imaging dosimetry teaching and demonstration applications.  All anatomical dimensions of the phantom are based on The Visible Human Project (VHP) data sets that serve as a reference for the study of human anatomy and are available through the National Library of Medicine.

CIRS has combined this anatomical detail with our advanced tissue mimicking technology.  The phantom is made from proprietary epoxy materials that mimic the density and radiation attenuation properties of human tissue within 1% from 50 keV to 25 MeV.  It contains anatomically precise bone, cartilage, spinal cord, vertebral disks, muscle, intestines, bladder, prostate, rectum and interstitial fat.

Features:
Based on the Visible Human Project data set

Superior tissue simulation and lifelike imaging properties

Accommodates wide variety of detectors

CIRS 801-P男性骨盤模體，CIRS 801-P模體實物拍攝圖：
